NPC Electric Delivers 500KVA 3-Phase Pad Mounted Transformers for Jamaica
2025-09-25
NPC Electric is proud to announce the successful delivery of high-performance solar PV transformers to support a major renewable energy project in Jamaica, scheduled for commissioning on August 18, 2025.
The shipment includes:
-
500KVA, 24kV, 415/240V, 3-Phase, Copper Winding, Oil-Cooled Pad-Mounted Transformer
Engineered with precision and built to international standards, these solar power distribution transformers feature copper windings and an oil-cooled pad-mounted design, ensuring high efficiency, stable performance, and long-term reliability in demanding environments. These transformers are specifically designed for solar PV applications, making them ideal for high-load operations and variable Caribbean climate conditions.
This milestone marks a significant step in NPC Electric’s expansion into the Caribbean renewable energy market. By combining robust manufacturing, strict quality control, efficient logistics, and responsive customer service, NPC Electric continues to drive the growth of Jamaica’s solar energy infrastructure.
As Jamaica accelerates its transition toward sustainable and green energy, NPC Electric is committed to delivering advanced transformer solutions that enable safe, reliable, and efficient power distribution for solar power projects across the region.
