19/33kV Underground Cables Successfully Dispatched to ATLAS Chile
2025-04-29
19/33kV underground cables have been successfully dispatched to ATLAS Chile. This delivery marks a significant step in supporting the infrastructure needs of the region.
Now we are pleased to share exciting news regarding our recent shipment. NPC Electric has successfully completed the delivery of the following cable products to ATLAS Chile:
| Name | Standards | Model |
| 19/33kV | CU/XLPE/CWS/LSZH | 1C × 150 sqmm |
| 19/33kV | CU/XLPE/CWS/LSZH | 1C × 630 sqmm |
This shipment marks another important milestone in our cooperation with ATLAS Chile and demonstrates our commitment to delivering high-quality products on schedule. We appreciate the trust and support from our client and look forward to strengthening our partnership through continued excellent service and reliable supply.
NPC ELECTRIC has provided so much cables to Chile Markets, Like the Mining cable, AAAC Conductor, ACAR Conductor,Solar Cable etc.
The shipment underscores our commitment to providing high-quality electrical solutions. We look forward to the positive impact these cables will have on ATLAS Chile's operations.
