Instrumentation Cables—XLPE Insulated,Individual & Overall Screened, DRYLAM Layered,Wire Armoured PVC Sheathed Cables(CU/XLPE/IOSCR/DRYLAM/SWA/PVC)
Instrumentation Cables with XLPE Insulated, Individual & Overall Screened, DRYLAM Layered, Wire Armoured and PVC Sheathed construction (CU/XLPE/IOSCR/DRYLAM/SWA/PVC) are engineered for high-accuracy signal transmission in harsh and moisture-prone environments. XLPE insulated copper conductors deliver excellent dielectric strength, thermal stability, and long-term electrical reliability.
Individual and overall screening effectively suppress electromagnetic interference and cross-talk, ensuring stable and precise signal performance in complex control systems. The integrated DRYLAM water-blocking layer prevents longitudinal and radial water penetration, protecting the cable core without increasing overall diameter. Steel wire armour provides strong mechanical protection against impact and external stress, while the PVC outer sheath offers resistance to abrasion, oils, and chemicals. This robust cable design ensures dependable operation, extended service life, and consistent performance in demanding industrial applications.
- Standard BS EN 50288-7, IEC 60502-1 (General)
Construction
Technical Specifications
Quality Control
Application
Construction
XLPE Insulated,Individual & Overall Screened, DRYLAM Layered,Wire Armoured PVC Sheathed Cables
Conductor
Instrumentation cable shall have an annealed plain copper conductor or a tinned copper conductor. Depending upon cable application, conductor can be solid (Class-1), Stranded (Class-2), or flexible (Class-5) type as defined in BS EN / IEC 60228
Insulation
Instrumentation cable shall have PVC, XLPE, or HR-PVC insulation. Insulation material shall be selected based on the maximum operating temperature. PVC insulation is suitable for a continuous operating temperature of 70°C, whereas XLPE or HR-PVC is suitable for a continuous operating temperature of 90°C. Fire-rated / fire resistance instrumentation cables shall have Glass Mica Tape layer below insulation & shall have XLPE insulation.
Individual and Overall Screen
The screen is made of aluminum, mylar tape, + ATC drain wire. Aluminum mylar tape is made of aluminum with a thin layer of polyester. It helps in minimizing the crosstalk and prevents shorting.
Armour
Steel wire armour is applied to cables to shield against mechanical stresses and ensure that the core of the cable remains protected.
Inner and Outer Sheath
The sheath can be made of PVC, Polyethylene, or LSZH
Technical Specifications
Instrumentation Cables—XLPE Insulated,Individual & Overall Screened, DRYLAM Layered,Wire Armoured PVC Sheathed Cables(CU/XLPE/IOSCR/DRYLAM/SWA/PVC)
Instrumentation Cables Main Specifications
Instrumentation Cables—XLPE Insulated,Individual & Overall Screened, DRYLAM Layered,Wire Armoured PVC Sheathed Cables(CU/XLPE/IOSCR/DRYLAM/SWA/PVC)
| Conductor Size | Max. Conductor DC Resistance at 20°C for Plain Copper |
Max. Conductor DC Resistance at 20°C for Tinned Copper |
||
| Solid, Class - 1 & Stranded, Class - 2 |
Flexible, Class-5 | Solid, Class - 1 & Stranded, Class - 2 |
Flexible, Class-5 | |
| [mm2] | [Ω/km] | [Ω/km] | [Ω/km] | [Ω/km] |
| 0.50 | 36.72 | 39.78 | 37.434 | 40.902 |
| 0.75 | 24.99 | 26.52 | 25.296 | 27.234 |
| 1.00 | 18.462 | 19.89 | 18.564 | 20.4 |
| 1.50 | 12.342 | 13.566 | 12.444 | 13.974 |
| 2.50 | 7.5582 | 8.1396 | 7.7112 | 8.3742 |
| Conductor Size | Insulation Thickness | |||
| 90V | 300V | 500V | 1000V | |
| [mm2] | [mm] | [mm] | [mm] | [mm] |
| 0.50 | 0.20 | 0.26 | 0.44 | 0.70 |
| 0.75 | 0.20 | 0.26 | 0.44 | 0.70 |
| 1.00 | 0.26 | 0.26 | 0.44 | 0.70 |
| 1.50 | 0.30 | 0.35 | 0.44 | 0.70 |
| 2.50 | - | - | 0.53 | 0.70 |
| Conductor Size | Mutual Capacitance | Max. Continuous Operating Temperature | Inductance to Resistance Ratio (L/R) |
||
| XLPE | PVC | XLPE or HR - PVC | PVC | ||
| [mm2] | [nF/km] | [nF/km] | [°C] | [°C] | [μH/Ω] |
| 0.50 | 150 | 250 | 90 | 70 | < 25 |
| 0.75 | 150 | 250 | 90 | 70 | < 25 |
| 1.00 | 150 | 250 | 90 | 70 | < 25 |
| 1.50 | 150 | 250 | 90 | 70 | < 40 |
| 2.50 | 150 | 250 | 90 | 70 | < 60 |
| Number of Pair | Cable OD | Cable Weight | Drum Length | ||||||||
| 0.5mm² | 0.75mm² | 1.0mm² | 1.5mm² | 2.5mm² | 0.5mm² | 0.75mm² | 1.0mm² | 1.5mm² | 2.5mm² | ||
| [Nos] | [mm] | [mm] | [mm] | [mm] | [mm] | [kg/km] | [kg/km] | [kg/km] | [kg/km] | [kg/km] | [m] |
| 2 | 20.0 | 20.5 | 21.5 | 22.5 | 25.0 | 590 | 630 | 665 | 740 | 870 | 1000 |
| 5 | 23.0 | 24.0 | 24.5 | 26.5 | 30.5 | 760 | 825 | 885 | 1010 | 1400 | 1000 |
| 10 | 29.0 | 30.5 | 32.0 | 34.5 | 40.0 | 1225 | 1355 | 1465 | 1680 | 2340 | 1000 |
| 20 | 39.5 | 42.0 | 44.0 | 48.0 | 56.5 | 2335 | 2650 | 2910 | 3440 | 4860 | 1000 |
| 30 | 39.5 | 42.0 | 44.0 | 48.0 | 2335 | 2650 | 2910 | 3440 | 500 | ||
| Number of Triad | Cable OD | Cable Weight | Drum Length | ||||||||
| 0.5mm² | 0.75mm² | 1.0mm² | 1.5mm² | 2.5mm² | 0.5mm² | 0.75mm² | 1.0mm² | 1.5mm² | 2.5mm² | ||
| [Nos] | [mm] | [mm] | [mm] | [mm] | [mm] | [kg/km] | [kg/km] | [kg/km] | [kg/km] | [kg/km] | [m] |
| 2 | 21.0 | 22.0 | 23.0 | 24.0 | 27.5 | 640 | 705 | 750 | 820 | 1135 | 1000 |
| 5 | 24.0 | 25.5 | 26.5 | 29.0 | 33.0 | 845 | 950 | 1030 | 1330 | 1640 | 1000 |
| 10 | 31.0 | 33.0 | 34.5 | 37.0 | 43.5 | 1390 | 1560 | 1720 | 1980 | 2810 | 1000 |
| 20 | 43.0 | 46.0 | 48.5 | 53.5 | 2730 | 3155 | 3570 | 4565 | 500 | ||
| 30 | 43.0 | 46.0 | 48.5 | 2730 | 3155 | 3570 | 500 | ||||
| Number of Quad | Cable OD | Cable Weight | Drum Length | ||||||||
| 0.5mm² | 0.75mm² | 1.0mm² | 1.5mm² | 2.5mm² | 0.5mm² | 0.75mm² | 1.0mm² | 1.5mm² | 2.5mm² | ||
| [Nos] | [mm] | [mm] | [mm] | [mm] | [mm] | [kg/km] | [kg/km] | [kg/km] | [kg/km] | [kg/km] | [m] |
| 2 | 23.0 | 24.0 | 24.5 | 26.5 | 30.5 | 730 | 790 | 845 | 955 | 1325 | 1000 |
| 5 | 27.5 | 29.0 | 30.5 | 32.5 | 36.5 | 1130 | 1255 | 1375 | 1560 | 1955 | 1000 |
| 10 | 34.5 | 36.5 | 39.0 | 43.0 | 49.0 | 1620 | 1845 | 2065 | 2655 | 3415 | 1000 |
| 20 | 48.5 | 53.0 | 56.0 | 3270 | 4165 | 4705 | 500 | ||||
| 30 | 48.5 | 3270 | 500 | ||||||||
Note: Cable OD and Cable weight are subject to change based on the latest manufacturing practice.
Quality Control
Instrumentation Cables—XLPE Insulated,Individual & Overall Screened, DRYLAM Layered,Wire Armoured PVC Sheathed Cables(CU/XLPE/IOSCR/DRYLAM/SWA/PVC)
Raw Material Test
Raw Material Test is the first quality control step for CU/XLPE/IOSCR/DRYLAM/SWA/PVC instrumentation cables. Copper conductors are tested for electrical conductivity, tensile strength, and dimensional tolerance. XLPE insulation compounds undergo thermal aging, elongation, and insulation resistance testing. Individual and overall screening materials are inspected for conductivity, coverage density, and shielding performance. DRYLAM water-blocking tapes and yarns are evaluated for swelling behavior and moisture absorption efficiency. Steel wire armour is tested for mechanical strength and flexibility, while PVC sheath materials are examined for flame retardancy, abrasion resistance, and environmental durability. Only qualified materials proceed to production.
Process inspection
Process Inspection ensures consistent manufacturing quality of CU/XLPE/IOSCR/DRYLAM/SWA/PVC instrumentation cables. XLPE insulation extrusion is monitored for concentricity and thickness accuracy. Individual and overall screening processes are inspected to ensure complete coverage and electrical continuity. DRYLAM layering is carefully checked for correct placement and effective water-blocking performance. Armouring operations are controlled for wire tension and lay length, ensuring mechanical integrity. PVC sheathing is inspected for surface quality and dimensional stability. Continuous in-process inspections maintain compliance with design and technical standards.
Finished Product
Finished Product Test verifies the final performance of CU/XLPE/IOSCR/DRYLAM/SWA/PVC instrumentation cables. Electrical tests include conductor resistance, insulation resistance, and voltage withstand testing. Mechanical tests assess tensile strength, bending capability, and impact resistance of the armoured structure. Water penetration tests confirm the effectiveness of the DRYLAM layer. Final visual inspection ensures correct construction, marking, and workmanship before approval for shipment.
Application
These cables are suitable for oil and gas facilities, power plants, chemical industries, water treatment systems, underground installations, and industrial automation requiring moisture protection and signal accuracy.
Technical Advantages
