Earth Transformer & Three Phase Pad Mounted Transformer Shipping to Chile | NPC Electric
2025-09-18
NPC Electric is proud to announce the successful shipment of high-performance transformer equipment to a major power project in Chile on July 6, 2025. This delivery strengthens our role as a trusted supplier of advanced power distribution solutions in Latin America.
Delivered Transformer Equipment to Chile
-
Earth Transformer 33kV 1100kVA
-
Three Phase Pad Mounted Transformer 150kVA, 33/0.38kV, Loop Feed, 50Hz
Advanced Design & International Standards
Engineered and manufactured to meet rigorous international standards, both transformers ensure high efficiency, low energy loss, and reliable performance.
-
The pad-mounted three-phase transformer, with its compact structure and loop feed design, provides enhanced flexibility and reliability for urban grids and industrial distribution networks.
-
The earth transformer is designed to deliver stable and safe power, supporting critical infrastructure needs in Chile.
Supporting Chile’s Power Infrastructure & Energy Transition
This successful shipment highlights NPC Electric’s strategic expansion in the Chilean energy market. By delivering innovative transformer technologies and customized power solutions, NPC Electric actively contributes to:
-
Modernization of Chile’s power infrastructure
-
Improved energy efficiency and sustainability
-
Long-term support for Chile’s clean energy transition
NPC Electric – Global Expertise, Local Commitment
With a global perspective and localized service, NPC Electric continues to work closely with partners across Chile and Latin America. Our mission is to provide safer, greener, and more efficient power distribution solutions, building a sustainable energy future together.
