Variable Frequency Drive (VFD) EMC 2YSL(st)CY Cable
The Variable Frequency Drive (VFD) EMC 2YSL(st)CY Cable is a flexible, low-voltage power and control cable designed for use with frequency-controlled drives. Built to DIN VDE 0250 standards, it features low capacitance, enhanced EMC shielding with aluminium-foil and tinned copper braid, and PVC outer sheath for durability. It provides excellent electromagnetic compatibility, oil and grease resistance, and reliable performance under medium mechanical stress. Ideal for connecting motors to inverters, this cable supports fixed and temporary installations in both indoor and outdoor environments (excluding direct burial).
- Voltage Rating Uo/U 0.6/1kV
-
Temperature Rating
Fixed: -30°C to +70°C
Flexed: -5°C to +70°C -
Minimum Bending Radius
Fixed: 10 x overall diameter
Flexed: 25 x overall diameter
Construction
Technical Specifications
Quality Control
Application
Construction
Variable Frequency Drive (VFD) EMC 2YSL(st)CY Cable Constrution
Conductor
Class 5 flexible copper conductor
Insulation
PE (Polyethylene)
Screen
Aluminium-Foil
Braid
TCWB (Tinned Copper Wire Braid)
Sheath
PVC (Polyvinyl Chloride)
Sheath Colour
Red
Manufacturer Standard
Standard:VDE 0250
Flame Retardant
IEC/EN 60332-1-2
Core Identification
3 core + earth: ● Grey ● Brown ● Black ● Green/Yellow
4 core: Grey Brown Black Green/Yellow
4 core: Grey Brown Black Green/Yellow
Application
Variable Frequency Drive (VFD) EMC 2YSL(st)CY Cable is used to connect motors to inverters while ensuring EMC compliance. It is suitable for fixed or temporary installations under medium mechanical stress, offering good oil and grease resistance for outdoor use (excluding direct burial).
Technical Specifications
Variable Frequency Drive (VFD) EMC 2YSL(st)CY Cable
Variable Frequency Drive (VFD) EMC 2YSL(st)CY Cable 0.6/1kV
|
No. Of Cores |
Nominal Cross Sectional Area mm² |
NOMINAL OVERALL DIAMETER |
NOMINAL WEIGHT |
|
|
Phase Conductor |
Earth Conductor |
mm | kg/km | |
| 3 + 3 earth | 1.5 | 0.25 | 10.2 | 140 |
| 3 + 3 earth | 2.5 | 0.5 | 11.4 | 220 |
| 3 + 3 earth | 4 | 0.75 | 13.1 | 323 |
| 3 + 3 earth | 6 | 1 | 14.9 | 420 |
| 3 + 3 earth | 10 | 1.5 | 18.4 | 615 |
| 3 + 3 earth | 16 | 2.5 | 21.6 | 819 |
| 3 + 3 earth | 25 | 4 | 25.3 | 1402 |
| 3 + 3 earth | 35 | 6 | 27.8 | 1718 |
| 3 + 3 earth | 50 | 10 | 32.6 | 2399 |
| 3 + 3 earth | 70 | 10 | 38.9 | 3173 |
| 3 + 3 earth | 95 | 16 | 44.3 | 4162 |
| 3 + 3 earth | 120 | 16 | 46.8 | 5253 |
| 3 + 3 earth | 150 | 25 | 53.5 | 6128 |
| 3 + 3 earth | 185 | 35 | 59.5 | 7450 |
| 3 + 3 earth | 240 | 50 | 70 | 10800 |
| 4 | 1.5 | - | 10.4 | 154 |
| 4 | 2.5 | - | 12.3 | 229 |
| 4 | 4 | - | 14.5 | 339 |
| 4 | 6 | - | 16.8 | 451 |
| 4 | 10 | - | 19.7 | 667 |
| 4 | 16 | - | 22 | 892 |
| 4 | 25 | - | 27 | 1440 |
| 4 | 35 | - | 30.3 | 1861 |
| 4 | 50 | - | 35 | 2547 |
| 4 | 70 | - | 39.4 | 3404 |
| 4 | 95 | - | 46 | 4888 |
| 4 | 120 | - | 51.4 | 5703 |
| 4 | 150 | - | 58.8 | 7040 |
| 4 | 185 | - | 61.1 | 9150 |
| 4 | 240 | - | 70 | 12500 |
Quality Control
Variable Frequency Drive (VFD) EMC 2YSL(st)CY Cable
Raw Material Test
Raw Material Test for Variable Frequency Drive (VFD) EMC 2YSL(st)CY Cable focuses on EMC shielding quality. Steps include: Certification Verification: Tinned copper conductors and PVC compounds meet IEC standards; foil and braid certified for shielding performance. Conductor Testing: Tensile, elongation, conductivity, tin coating analysis. Insulation & Semi-Conductive Check: PVC tensile/elongation/dielectric strength; semi-conductive layer resistivity/adhesion. Shielding Material Evaluation: Aluminum foil thickness/adhesion/coverage; tinned copper braid optical coverage (>85%), braid angle, and conductivity. Sheath Testing: Oil/UV/abrasion resistance, flame retardancy. Batch Rejection: Non-compliant quarantined. Approved materials ensure the Variable Frequency Drive (VFD) EMC 2YSL(st)CY Cable's EMC effectiveness and durability.
Process inspection
Process Inspection for Variable Frequency Drive (VFD) EMC 2YSL(st)CY Cable upholds double-shielding precision. The procedure features: Stranding Control: Uniform tinned copper stranding. Insulation Extrusion: PVC applied with defect sensors. Shielding Application: Foil with 100% overlap + high-coverage braid monitored. Sheath Extrusion: PVC sheath thickness/adhesion checked. Ongoing Checks: Resistance, capacitance, shielding continuity. Correction: Immediate fixes. This guarantees the Variable Frequency Drive (VFD) EMC 2YSL(st)CY Cable excels in EMC suppression and VFD performance.
Finished Product
Finished Product Test validates the Variable Frequency Drive (VFD) EMC 2YSL(st)CY Cable for market. Steps include: Inspection: Visual/dimensional/marking verification. Electrical: Resistance, insulation, high-voltage withstand, capacitance. EMC Testing: Transfer impedance, screening attenuation, emission tests. Mechanical: Bending, tensile, abrasion resistance. Environmental: Oil/flame/UV aging checks. Release: Only passing Variable Frequency Drive (VFD) EMC 2YSL(st)CY Cable approved for reliable VFD motor use.
Application
The Variable Frequency Drive (VFD) EMC 2YSL(st)CY Cable suits VFD motor connections in automation systems, pumps, fans, compressors, cranes, textile machines, and production lines where long cable runs, strong EMC suppression, low bearing currents, and reliable motor operation are required.
Technical Advantages
● 30+ years of manufacturing experience
● ISO and UL certified production
● Customized cable and transformer solutions
